© 2003 Prentice-Hall, Inc.
Basic Business Statistics
Chapter 3
Numerical Descriptive Measures
Chapters Objectives:
Learn about Measures of Center.
How to calculate mean, median and midrange
Learn about Measures of Spread
Learn how to calculate Standard Deviation, IQR and
Range
Learn about 5 number summaries
Coefficient of Correlation
© 2003 Prentice-Hall, Inc.
Chapter Topics
 Measures of Central Tendency
 Mean, Median, Midrange,
 Quartile
 Measure of Variation
 Range, Interquartile Range, Variance and
Standard Deviation, Shape
 Symmetric, Skewed, Using Box-and-Whisker Plots
© 2003 Prentice-Hall, Inc.
Chapter Topics
Coefficient of Correlation
 Pitfalls in Numerical Descriptive Measures
and Ethical Issues
(continued)
© 2003 Prentice-Hall, Inc.
Summary Measures
Central Tendency
Mean
Median
Mode
Quartile
Mid Range
Summary Measures
Variation
Variance
Standard Deviation
Range
Not very good
measure
© 2003 Prentice-Hall, Inc.
The Second Step of Data
Analysis
 We looked at displaying data using graphs.
 But numeric summaries help us to compare variables and to
talk about relationships among variables in precise (exact)
ways.
 After drawing the graph, it is usual to calculate summary
values.
 This Lesson considers a different numerical summaries.
© 2003 Prentice-Hall, Inc.
Summaries of Center and Spread
Can you think of a way of estimating the
 Center of this histogram or
 How wide it is (Spread or Variance)
Measure
of Center
Measure
of Spread
Mean Standard
Deviation
Media IQR
Midrange Range0
5
10
15
20
25
30
30-40 40-50 50-60 60-70 70-80 80-90 90-100
•The shape that appears over the histogram is called the normal distribution shape
•This shape is used to estimate the shape of the histogram
© 2003 Prentice-Hall, Inc.
Finding the Central
Value
 We summarize the distribution with mean
median and midrange
 The mean median and midrange have
different idea of what is the center, and
behaves differently
 The Mode is also used however this is not
a good measure of the central value
© 2003 Prentice-Hall, Inc.
Measures of Central Tendency
Central Tendency
Mean Median Midrange
1
1
n
i
i
N
i
i
X
X
n
X
N
µ
=
=
=
=
∑
∑
© 2003 Prentice-Hall, Inc.
Mean (Arithmetic Mean)
 Mean (Arithmetic Mean) of Data Values
 Sample mean
 Population mean
1 1 2
n
i
i n
X
X X X
X
n n
= + + +
= =
∑ L
1 1 2
N
i
i N
X
X X X
N N
µ = + + +
= =
∑ L
Sample Size
Population Size
© 2003 Prentice-Hall, Inc.
Mean (Arithmetic Mean)
 The Most Common Measure of Central
Tendency
 Affected by Extreme Values (Outliers)
(continued)
0 1 2 3 4 5 6 7 8 9 10 0 1 2 3 4 5 6 7 8 9 10 12 14
Mean = 5 Mean = 6
© 2003 Prentice-Hall, Inc.
 Approximating the Arithmetic Mean
 Used when raw data are not available

Mean (Arithmetic Mean)
(continued)
1
sample size
number of classes in the frequency distribution
midpoint of the th class
frequencies of the th class
c
j j
j
j
j
m f
X
n
n
c
m j
f j
=
=
=
=
=
=
∑
© 2003 Prentice-Hall, Inc.
How to compute the Mean?
Step 1: Add all the data points. This is called the SUM or the Total
Step 2: Count the number of Data points. This is sometimes called
the count
Step 3: Divide The Total by the Number of Data points
Calculate the mean for
the following data
points. 5,20,15,3,7
Revision: 5.1 Know how to compute the mean of a collection of data
values.
© 2003 Prentice-Hall, Inc.
Median
 Robust Measure of Central Tendency
 Not Affected by Extreme Values
 In an Ordered Array, the Median is the
‘Middle’ Number
 If n or N is odd, the median is the middle number
 If n or N is even, the median is the average of the 2
middle numbers
0 1 2 3 4 5 6 7 8 9 10 0 1 2 3 4 5 6 7 8 9 10 12 14
Median = 5 Median = 5
© 2003 Prentice-Hall, Inc.
Example: Find median of the following numbers
14.1 3.2 25.3 2.8 -17.5 13.9 45.8
Step 1 Order the data
1 2 3 4 5 6 7
-17.5 2.8 3.2 13.9 14.1 25.3 45.8
Step 2 There are 7 values
n is odd
Step 3 a Median is the middle number
Median is 13.9
If we added 35.7 to the above numbers (data set) . What would the median now be?
14.1 3.2 25.3 2.8 -17.5 13.9 45.8 35.7
Step 3 b Median is average of the two middle numbers
5 position 14.1
4 position 13.9
Median = '(13.9+14.1)/2= 14
1 2 3 4 5 6 7 8
-17.5 2.8 3.2 13.9 14.1 25.3 35.7 45.8
Step 1 Order the data
n is even
Step 2 There are 8 values
Calculate the median
for the following data
points. 5,20,15,3,7
Calculate the median
for the following data
points. 5,20,15,3,7,10
MEDIAN
MEDIAN between 13.9 and 14.1
© 2003 Prentice-Hall, Inc.
How to compute the Midrange
 The range of the data is defined as the difference
between the Maximum and Minimum (Range =
Max – Min)
 What would the Range be in the previous
example?
 What would the midrange be? (max + min)/2
 DISADVANTAGE: - one extreme value can make
the midrange very large, so it does not really
represent the data.
 If you deleted 45.8 and added 1000 to the previous
example what would the midrange be?
63.3
14.15
491.25
Calculate the midrange and range for the following data points.
5,20,15,3,7
© 2003 Prentice-Hall, Inc.
Summary Measures of center
 Measures of center are the most commonly
used (and misused) summaries of data.
 If you understand how they differ and what
they really say you can avoid
misunderstanding data or being fooled by
inappropriate summaries.
© 2003 Prentice-Hall, Inc.
Mode
 A Measure of Central Tendency
 Value that Occurs Most Often
 Not Affected by Extreme Values
 There May Not Be a Mode
 There May Be Several Modes
 Used for Either Numerical or Categorical Data
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14
Mode = 9
0 1 2 3 4 5 6
No Mode
© 2003 Prentice-Hall, Inc.
Why the mode is not really a measure of
center
 Often listed among measures of center.
 Is it really a central value?
1. The mode of a categorical variable is the category with the highest
frequency.

It is not a center in because the categories of a categorical
variable have no specific order

we can choose to place the modal category in a bar chart on the
right, on the left, or in the middle..
2. When a continuous distribution is unimodal and symmetric, the
single, central mode is often near to other measures of center.
3. Modes of data measured on quantitative variables are rarely useful
as measures of center.

It is a coincidence when two quantitative measurements agree
exactly,

counting such occurrences tells us little about the variable. As a
consequence, statistics packages rarely compute or report
modes.
© 2003 Prentice-Hall, Inc.
Quartiles
 Split Ordered Data into 4 Quarters
 Position of i-th Quartile
 Q1 and Q3 are Measures of Noncentral Location
 Q2= Median, a Measure of Central Tendency
 The calculation will be covered in the IQR slides.
25% 25% 25% 25%
( )1Q ( )2Q ( )3Q
( )
( )1
4
i
i n
Q
+
=
Do not use formula in the Business Statistics BookDo not use formula in the Business Statistics Book
© 2003 Prentice-Hall, Inc.
Know the differing properties of the
mean, median, and midrange
 The most common summary value describing a
distribution of data values is some measure of a typical
or central value.
 This can be the mean, median or midrange
You have calculate the 3 measures of center (mean, median and
midrange) for the following data points. 5,20,15,3,7.
1. Change 15 to 19 and recalculate the mean, median and midrange.
Which measures of center have changed?
2. Change 20 to 200 and recalculate the mean, median and midrange.
Which measures of center have changed?
The median is not effected by outliers like the midrange and Mean
The mean is effected by very small changes to data
© 2003 Prentice-Hall, Inc.
Why Measures Spread?
 Spread measures how often something varies.
 Imagine you go to a restaurant and received such very good
meal, you return for the same meal the next day.
 However, this time the food tastes very bad. You never go back.
The standard of quality has varied.
 The restaurant management needs to be able to control the
quality of food.
 A key aspect of management is to reduce variability, and
provide a consistent quality of service or product
 The first step to control variability is to measure it.
 Then you can work out what causes the variability
 Then work out how to reduce variability.
© 2003 Prentice-Hall, Inc. Days of Week
The following shows the number of Cakes made by a Bakery in Phnom Penh.
It has two bakeries producing identical cakes
Day 1 Day 2 Day 3 Day 4 Day 5
Center
(Mean)
Spread
(Std Dev)
Bakery A 550 750 800 750 500 670 135
Bakery B 625 670 650 675 630 650 23
Total 1175 1420 1450 1425 1130
The bakery has to produce at least 1200 cakes to meet daily customer demand
The bakery has to produce can not produce more than 1400 cakes because
customers will not buy them and they will not be eaten
500
550
600
650
700
750
800
Day 1 Day 2 Day 3 Day 4 Day 5
NoCakesbaked
Bakery A
Bakery B
Mean A
Mean B
Spread A is 135.
Variance is very
high
Spread B is 23
The two bakeries have been baking too many or too few cakes each
day. Why?
© 2003 Prentice-Hall, Inc.
Different Summaries of Spread
 Summaries of Spread include
 Range
 Interquartile Range (IQR) and
 Standard Deviation
 These summaries highlight different aspects of the
distribution and have different values
 But they all summarize how the values are spread
out.
 We have already seen that Range = Max - Min
© 2003 Prentice-Hall, Inc.
Measures of Variation
Variation
Variance Standard Deviation Coefficient
of Variation
Population
Variance
Sample
Variance
Population
Standard
Deviation
Sample
Standard
Deviation
Range
Interquartile Range
© 2003 Prentice-Hall, Inc.
Range
 Measure of Variation
 Difference between the Largest and the
Smallest Observations:
 Ignores How Data are Distributed
Largest SmallestRange X X= −
7 8 9 10 11
12
Range = 12 - 7 = 5
7 8 9 10 11
12
Range = 12 - 7 = 5
© 2003 Prentice-Hall, Inc.
 Measure of Variation
 Also Known as Midspread
 Spread in the middle 50%
 Difference between the First and Third
Quartiles
 Not Affected by Extreme Values
3 1Interquartile Range 17.5 12.5 5Q Q= − = − =
Interquartile Range
Data in Ordered Array: 11 12 13 16 16 17 17 18 21
1317 4
© 2003 Prentice-Hall, Inc.
5 Steps to calculate the
Interquartile Range (IQR)
 Step 1 Put the data in Order
 Step 2 Divide the dataset in two. Dataset 1 and Dataset 2.
 NOTE: If n is odd the median should be included in both data sets
 Step 3 Calculate Q1 (25th
Percentile)
 If n of Dataset 1 is odd, the Q1 is the middle number of Dataset A
 If n of Dataset 1 is even, the median is the average of the 2 middle
numbers
 Step 4 Calculate Q3 (75th percentile)
 As per step 3
 Step 5 Find The Interquartile Range (IQR)
 IQR= Q3-Q1
© 2003 Prentice-Hall, Inc.
5 Steps to Calculate Q1, Q3 and IQR when n is odd
In order to calculate IQR we need to to first of all calculate Q1 and
Q3.
We are going to calculate the Q1, Q3 and IQR for the following
dataset: 7,8,25,11,13,5,6
We require to know: Median (Q2 or 50th
percentile), Q1 (25th
Percentile), Q3 (75th
percentile)
Step 1 Order Data
1
2 3 4 5 6 7
5 6 7 8 11 13 25
© 2003 Prentice-Hall, Inc.
Step 2 Divide the dataset in two
Divide the above data set into Dataset 1 and Dataset 2.
NOTE: If n is odd the median should be included in both data sets
Dataset 1 is used to calculate Q1 and Dataset 2 is used to calculate Q3
Dataset 1 For Q1 Data Set 2 For Q3
1 2 3 4 1 2 3 4
5 6 7 8 8 11 13 25
Step 3 Calculate Q1 (25th
Percentile)
N is even so the Q1 is the average of the 2 middle numbers
which is position 2 and 3
Q1 = (6+7)/2 =6.5
(This is the same method used to calculate the median for a
even number of data points)
5 Steps Calculate Q1, Q3 and IQR when n is odd (Cont)
© 2003 Prentice-Hall, Inc.
Step 4 Calculate Q3 (75th percentile)
N is even for dataset 2, the median is the average of the 2 middle
numbers which is position 2 and 3
Thus, Q3 = (11+13)/2 =12
Step 5 Find The Interquartile Range (IQR)
IQR= Q3-Q1 = 12-6.5 =5.5
5 Steps to Calculate Q1, Q3 and IQR when n is odd(Cont)
1 2 3 4
8 11 13 25
Calculate the Q1, Q3 and IQR for the following data points.
5,20,15,3,7,16,4
© 2003 Prentice-Hall, Inc.
5 Steps to Calculate Q1, Q3 and IQR when n is EVEN
When n is even we we use almost the same process to calculate Q1
Q3 and IQR. In order to calculate IQR we need to to first of all
calculate Q1 and Q3.
We are going to calculate the Q1, Q3 and IQR for the following
dataset: 7,8,25,11,13,5,6 and 30
We require to know: Q1 (25th Percentile), Q3 (75th
Step 1 Order Data
1
2 3 4 5 6 7 8
5 6 7 8 11 13 25 30
© 2003 Prentice-Hall, Inc.
Step 2 Divide the dataset in two
Divide the above data set into Dataset 1 and Dataset 2.
Dataset 1 is used to calculate Q1 and Dataset 2 is used to calculate Q3
Dataset 1 For Q1 Dataset 2 For Q3
1 2 3 4 1 2 3 4
5 6 7 8 11 13 25 30
Step 3 Calculate Q1 (25th
percentile)
N is even so the Q1 is the average of the 2 middle numbers
which is position 2 and 3
Q1 = (6+7)/2 =6.5
(This is the same method used to calculate the median for
a even number of data points)
5 Steps: Calculate Q1, Q3 and IQR when n is even (Cont)
© 2003 Prentice-Hall, Inc.
Step 4 Calculate Q3 (75th percentile)
N is even so the Q1 is the average of the 2 middle numbers
which is position 2 and 3
Thus, Q3 = (13+25)/2 =19
Step 5 Find The Interquartile Range (IQR)
IQR= Q3-Q1 =19-6.5=12.5
5 Steps to Calculate Q1, Q3 and IQR when n is even (Cont)
1 2 3 4
11 13 25 30
Calculate the Q1, Q3 and IQR for the following data points.
5,20,15,3,7,16,4,30
© 2003 Prentice-Hall, Inc.
( )
2
2 1
N
i
i
X
N
µ
σ =
−
=
∑
 Important Measure of Variation
 Shows Variation about the Mean
 Sample Variance:
 Population Variance:
( )
2
2 1
1
n
i
i
X X
S
n
=
−
=
−
∑
Variance
© 2003 Prentice-Hall, Inc.
Standard Deviation
 Most Important Measure of Variation
 Shows Variation about the Mean
 Has the Same Units as the Original Data
 Sample Standard Deviation:
 Population Standard Deviation:
( )
2
1
1
n
i
i
X X
S
n
=
−
=
−
∑
( )
2
1
N
i
i
X
N
µ
σ =
−
=
∑
© 2003 Prentice-Hall, Inc.
How to Calculate the Standard Deviation?
Step 1 Step 2 Step 3 Step 4
Count Data (y) Mean (y-Mean)
1 3.4 33.35 -29.95 897
2 20 33.35 -13.35 178
3 63 33.35 29.65 879
4 47 33.35 13.65 186
Total 133.4 2141 Step 5
Mean = SUM/Count =133.4/4=33.35 33.35
Step 6 Total Step 5/( Count -1)=2141/(4-1) = 713.6
Step 7 Square root of 713.6= 26.7
Steps to Calc Standard
Deviation
1: Calculate the Mean
=Sum/Count
Steps to Calc Standard
Deviation
1: Calculate the Mean
=Sum/Count
2: Enter the mean on each
line on the table
Steps to Calc Standard
Deviation
1: Calculate the Mean
=Sum/Count
2: Enter the mean on each
line on the table
3: Take the each data
point from the mean
Steps to Calc Standard
Deviation
1: Calculate the Mean
=Sum/Count
2: Enter the mean on each
line on the table
3: Take the each data
point from the mean
4: Square the answer to
Step 3 (Multiply each data
point by each other)
Steps to Calc Standard
Deviation
1: Calculate the Mean
=Sum/Count
2: Enter the mean on each
line on the table
3: Take the each data
point from the mean
4: Square the answer to
Step 3 (Multiply each data
point by each other)
5: Sum the all the data
points
6: Divide the total for Step
5 by (Count -1)
7: Calculate the square
root of Step 6
Steps to Calc Standard
Deviation
1: Calculate the Mean
=Sum/Count
2: Enter the mean on each
line on the table
3: Take the each data
point from the mean
4: Square the answer to
Step 3 (Multiply each data
point by each other)
5: Sum the all the data
points
6: Divide the total for Step
5 by (Count -1)
Steps to Calculate
Standard Deviation
1: Calculate the Mean
=Sum/Count
2: Enter the mean on each
line on the table
3: Take the each data
point from the mean
4: Square the answer to
Step 3 (Multiply each data
point by each other)
5: Sum the all the data
points
Calculate the Standard
Deviation for the following
data points. 5,20,15,3,7,16,4
© 2003 Prentice-Hall, Inc.
Histograms to display measures of spread
 When the distribution of data is unimodal and
symmetric, the middle 38% of the distribution
is about one standard deviation wide.
 This rule of thumb provides a way to display
the standard deviation, but it only applies to
unimodal, symmetric distributions.
 We can display common measures of spread
in a Histogram.
© 2003 Prentice-Hall, Inc.
Comparing Standard Deviations
Mean = 15.5
s = 3.338
11 12 13 14 15 16 17 18 19 20 21
11 12 13 14 15 16 17 18 19 20 21
Data B
Data A
Mean = 15.5
s = .9258
11 12 13 14 15 16 17 18 19 20 21
Mean = 15.5
s = 4.57
Data C
© 2003 Prentice-Hall, Inc.
Shape of a Distribution
 Describe How Data are Distributed
 Measures of Shape
 Symmetric or skewed
Mean = Median =ModeMean < Median < Mode Mode < Median < Mean
Right-SkewedLeft-Skewed Symmetric
© 2003 Prentice-Hall, Inc.
Describing Distribution:
Shape, Center and Spread
Start by displaying the distribution of your data. You should describe:
 Symmetry vs. skewness * (Look at the tails)
 Single vs. multiple modes
 Possible outliers separated from the main body of the data.
... But remember that not all distributions have simple shapes.
Symmetry Skewness
Unimodel Bimodel multimodal Uniform
Outliers
© 2003 Prentice-Hall, Inc.
Identifying Distribution Shape
When looking at the distribution of a quantitative
variable, consider:
 Symmetry,
 How many modes it has,
 Whether it has any outliers or gaps.
© 2003 Prentice-Hall, Inc.
Summary: Describing a Distribution
 You should always begin analyzing data by graphing the
distributions of the variables.
 We describe the shape of the distribution of a quantitative
variable by noting whether it is symmetric or skewed,
unimodal, bimodal, or multimodal.
 Following the general rule that we first describe a
pattern and then look for deviations from that
pattern, we look at distributions to see if there are straggling
outliers or gaps in the distribution shape.
 Each of these descriptions is quite general and vague, so
people may disagree on the "close calls." Nevertheless, we
usually begin describing data by summarizing the distribution
shapes.
© 2003 Prentice-Hall, Inc.
Exploratory Data Analysis
 Box-and-Whisker
 NOTE: Different from Basic Business Statistics Book!
 Graphical display of data using 5-number summary
Median( )
4 6 8 10 12
Top of
Whiskers
Bottom of
Whiskers
1Q 3Q
2Q
© 2003 Prentice-Hall, Inc.
Distribution Shape &
Box-and-Whisker
Right-SkewedLeft-Skewed Symmetric
1Q 1Q 1Q2Q 2Q 2Q3Q 3Q3Q
© 2003 Prentice-Hall, Inc.
The Empirical Rule
 For Most Data Sets, Roughly 68% of the
Observations Fall Within 1 Standard Deviation
Around the Mean
 Roughly 95% of the Observations Fall Within
2 Standard Deviations Around the Mean
 Roughly 99.7% of the Observations Fall
Within 3 Standard Deviations Around the
Mean
© 2003 Prentice-Hall, Inc.
Coefficient of Correlation
 Measures the Strength of the Linear
Relationship between 2 Quantitative Variables

( )( )
( ) ( )
1
2 2
1 1
n
i i
i
n n
i i
i i
X X Y Y
r
X X Y Y
=
= =
− −
=
− −
∑
∑ ∑
© 2003 Prentice-Hall, Inc.
Features of Correlation
Coefficient
 Unit Free
 Ranges between –1 and 1
 The Closer to –1, the Stronger the Negative
Linear Relationship
 The Closer to 1, the Stronger the Positive
Linear Relationship
 The Closer to 0, the Weaker Any Linear
Relationship
© 2003 Prentice-Hall, Inc.
Scatter Plots of Data with
Various Correlation Coefficients
Y
X
Y
X
Y
X
Y
X
Y
X
r = -1 r = -.6 r = 0
r = .6 r = 1
© 2003 Prentice-Hall, Inc.
Scatter Plots
 Best way to see relationships between two Quantitative Variables
 If there is a relationship it is called an association. Scatter plots are
the best way to look for associations
Relationship of Class Attended and Statitstics Score
20
25
30
35
40
45
50
55
60
65
70
4 6 8 10 12 14
Number Classes Attended
Score
© 2003 Prentice-Hall, Inc.
Scatter Plots
 Only Quantitative Variables can be used
 The following is the relationship between the Mango Taste
Score and the Number of Weeks it grown for
Weeks Grown on Tree
Time taken to grow the best Mango
0
20
40
60
80
100
6 8 10 12 14 16 18
TasteScore
© 2003 Prentice-Hall, Inc.
Direction: Positive
0
10
20
30
40
50
60
70
80
90
100
0 1 2 3 4 5 6
Scatter Plots : DIRECTION and FORM
Negtive Direction
0
10
20
30
40
50
60
70
80
90
0 1 2 3 4 5 6
•Direction: +Ve
•Form: Linear (Straight Line)
•Direction: +Ve
•Form: Linear (Straight Line)
© 2003 Prentice-Hall, Inc.
Form describes the shape
 Describe the Form if there is one. EG Straight, or
arched or curved
A Curve
0
2
4
6
8
10
12
14
16
18
20
0 1 2 3 4 5 6
An Arch
0
20
40
60
80
100
6 8 10 12 14 16 18
TasteScore
© 2003 Prentice-Hall, Inc.
Scatter: The following Scatter Plots have no scatter
0
50
100
150
200
250
0 5 10 15 20
0
5
10
15
20
25
30
0 2 4 6 8 10 12
•The third thing to look for is scatter.
•These graphs have no Scatter because the dots follow each other in a line.
© 2003 Prentice-Hall, Inc.
Scatter: The following Scatter Plots have scatter
•These graphs have Scatter because the dots are like a cloud.
•Always look for something you do not expect to find
•One Graph has an outlier which are very important unexpected points
that may occur
0
2
4
6
8
10
12
0 10 20 30 40 50
0
10
20
30
40
50
60
70
80
90
0 10 20 30 40 50 60
© 2003 Prentice-Hall, Inc.
How to Measure Scatter: Correlation Coefficient, r
I X Y
1 2 5 -4 -10 40
2 4 10 -2 -5 10
3 6 15 0 0 0
4 8 20 2 5 10
5 10 25 4 10 40
Total 30 75 100
Mean 6 15
Standard Deviation 3.162278 7.905694
Sx = 3.162278 Sy = 7.905694
1
905694.7*162278.3*)15(
100
)1(
)(*)(
=
−
=
−
−−
=
∑
SxSyn
yyxx
CorrCoef
xx −
xx − yy −
)(*)( yyxx −−
© 2003 Prentice-Hall, Inc.
Plot Chart and describe scatter plot. Calculate
Correlation Coefficient
0
10
20
30
0 5 10 15
X
Y
These data points go in straight
line with no scatter in a positive
direction (positively correlated)
1
905694.7*162278.3*)15(
100
)1(
)(*)(
=
−
=
−
−−
=
∑
SxSyn
yyxx
CorrCoef
Step 1: Draw Scatter Plot
Step 2: Write Description
Step 3: If there is a linear
(Straight line) relationship
calculate
© 2003 Prentice-Hall, Inc.
Example 2
 For the following data, plot a scatter plot and
describe it. Calculate Correlation Coefficient
n X Y X-Mean X Y-Mean X Product
1 4 22 -2 7.6 -15.2
2 5 23 -1 8.6 -8.6
3 6 12 0 -2.4 0
4 7 13 1 -1.4 -1.4
5 8 2 2 -12.4 -24.8
Total 30 72 -50
Mean 6 14.4
Standard Deviation 1.581139 8.561542
© 2003 Prentice-Hall, Inc.
Answer: Example 2
n X Y
1 4 22 -2 7.6 -15.2
2 5 23 -1 8.6 -8.6
3 6 12 0 -2.4 0
4 7 13 1 -1.4 -1.4
5 8 2 2 -12.4 -24.8
Total 30 72 -50
Mean 6 14.4
Standard Deviation 1.581139 8.561542
These data points go in straight
line with some scatter in a negative
direction (negatively correlated)
0
5
10
15
20
25
3 4 5 6 7 8 9
x
y
92.0
1214.9*5811.1*)15(
50
)1(
)(*)(
−=
−
−
=
−
−−
=
∑
SxSyn
yyxx
CorrCoef
xx − yy −
)(*)( yyxx −−
© 2003 Prentice-Hall, Inc.
Example 3
 For the following data, plot a scatter plot and
describe it. Calculate Correlation Coefficient
n X Y X-Mean X Y-Mean X Product
1 1 5 -2 -10.2 20.4
2 2 21 -1 5.8 -5.8
3 3 25 0 9.8 0
4 4 19 1 3.8 3.8
5 5 6 2 -9.2 -18.4
Total 15 76 0
Mean 3 15.2
Standard Deviation 1.581139 9.121403
© 2003 Prentice-Hall, Inc.
Answer: Example 3
n X Y
1 1 5 -2 -10.2 20.4
2 2 21 -1 5.8 -5.8
3 3 25 0 9.8 0
4 4 19 1 3.8 3.8
5 5 6 2 -9.2 -18.4
Total 15 76 0
Mean 3 15.2
Standard Deviation 1.581139 9.121403
0
10
20
30
0 2 4 6
X
Y
These data points are in an arched
shape with a little scatter.
0
1214.9*5811.1*)15(
0
)1(
)(*)(
=
−
=
−
−−
=
∑
SxSyn
yyxx
CorrCoef
xx − yy −
)(*)( yyxx −−
© 2003 Prentice-Hall, Inc.
Example 4
 For the following data, plot a scatter plot and
describe it. Calculate Correlation Coefficient
n X Y X-Mean X Y-Mean X Product
1 1 17 -4.4 5.8 -25.52
2 3 1 -2.4 -10.2 24.48
3 6 22 0.6 10.8 6.48
4 7 3 1.6 -8.2 -13.12
5 10 13 4.6 1.8 8.28
Total 27 56 0.6
Mean 5.4 11.2
Standard Deviation 3.507136 9.011104
© 2003 Prentice-Hall, Inc.
Answer: Example 4
n X Y X-Mean X Y-Mean X Product
1 1 17 -4.4 5.8 -25.52
2 3 1 -2.4 -10.2 24.48
3 6 22 0.6 10.8 6.48
4 7 3 1.6 -8.2 -13.12
5 10 13 4.6 1.8 8.28
Total 27 56 0.6
Mean 5.4 11.2
Standard Deviation 3.507136 9.011104
0
10
20
30
0 5 10 15
X
Y
0.005
9.011*3.5071*1)(5
6.0
1)SxSy(n
)y(y*)x(x
CorrCoef
=
−
=
−
−−
=
∑
These data points have a lot of
scatter and they are not correlated
© 2003 Prentice-Hall, Inc.
Pitfalls in Numerical Descriptive
Measures and Ethical Issues
 Data Analysis is Objective
 Should report the summary measures that best meet the
assumptions about the data set
 Data Interpretation is Subjective
 Should be done in a fair, neutral and clear manner
 Ethical Issues
 Should document both good and bad results
 Presentation should be fair, objective and neutral
 Should not use inappropriate summary measures to distort
the facts
© 2003 Prentice-Hall, Inc.
Chapter Summary
 Described Measures of Central Tendency
 Mean, Median, Midrange
 Discussed Quartiles
 Described Measures of Variation
 Range, Interquartile Range, Variance and
Standard Deviation
 Illustrated Shape of Distribution
 Symmetric, Skewed, Using Box-and-Whisker Plots
© 2003 Prentice-Hall, Inc.
Chapter Summary
 Described the Empirical
 Discussed Correlation Coefficient
 Addressed Pitfalls in Numerical Descriptive
Measures and Ethical Issues
(continued)
Ad

More Related Content

What's hot (20)

Business Statistics Chapter 1
Business Statistics Chapter 1Business Statistics Chapter 1
Business Statistics Chapter 1
Lux PP

Bbs11 ppt ch03
Bbs11 ppt ch03Bbs11 ppt ch03
Bbs11 ppt ch03
Tuul Tuul

Business Statistics Chapter 2
Business Statistics Chapter 2Business Statistics Chapter 2
Business Statistics Chapter 2
Lux PP

Business statistics
Business statistics Business statistics
Business statistics
Sajjad Chitrali

Business Statistics Chapter 9
Business Statistics Chapter 9Business Statistics Chapter 9
Business Statistics Chapter 9
Lux PP

Chap01 intro & data collection
Chap01 intro & data collectionChap01 intro & data collection
Chap01 intro & data collection
Uni Azza Aunillah

Business Statistics Chapter 8
Business Statistics Chapter 8Business Statistics Chapter 8
Business Statistics Chapter 8
Lux PP

Chapter 1 introduction to statistics
Chapter 1 introduction to statisticsChapter 1 introduction to statistics
Chapter 1 introduction to statistics
John Carlo Catacutan

Chap03 numerical descriptive measures
Chap03 numerical descriptive measuresChap03 numerical descriptive measures
Chap03 numerical descriptive measures
Uni Azza Aunillah

Business Statistics Chapter 6
Business Statistics Chapter 6Business Statistics Chapter 6
Business Statistics Chapter 6
Lux PP

Forecasting-Exponential Smoothing
Forecasting-Exponential SmoothingForecasting-Exponential Smoothing
Forecasting-Exponential Smoothing
iceu novida adinata

Introduction to business statistics
Introduction to business statisticsIntroduction to business statistics
Introduction to business statistics
Aakash Kulkarni

Time series
Time seriesTime series
Time series
Hasnain Baber

Chap02 presenting data in chart & tables
Chap02 presenting data in chart & tablesChap02 presenting data in chart & tables
Chap02 presenting data in chart & tables
Uni Azza Aunillah

Statistics: Chapter One
Statistics: Chapter OneStatistics: Chapter One
Statistics: Chapter One
Saed Jama

Case study on Business Statistics
Case study on Business Statistics Case study on Business Statistics
Case study on Business Statistics
Aditya Purohit

Statistics for management
Statistics for managementStatistics for management
Statistics for management
John Prarthan

Basic Probability
Basic ProbabilityBasic Probability
Basic Probability
Yesica Adicondro

Chapter 02
Chapter 02Chapter 02
Chapter 02
bmcfad01

Chap04 basic probability
Chap04 basic probabilityChap04 basic probability
Chap04 basic probability
Uni Azza Aunillah

Business Statistics Chapter 1
Business Statistics Chapter 1Business Statistics Chapter 1
Business Statistics Chapter 1
Lux PP

Bbs11 ppt ch03
Bbs11 ppt ch03Bbs11 ppt ch03
Bbs11 ppt ch03
Tuul Tuul

Business Statistics Chapter 2
Business Statistics Chapter 2Business Statistics Chapter 2
Business Statistics Chapter 2
Lux PP

Business Statistics Chapter 9
Business Statistics Chapter 9Business Statistics Chapter 9
Business Statistics Chapter 9
Lux PP

Chap01 intro & data collection
Chap01 intro & data collectionChap01 intro & data collection
Chap01 intro & data collection
Uni Azza Aunillah

Business Statistics Chapter 8
Business Statistics Chapter 8Business Statistics Chapter 8
Business Statistics Chapter 8
Lux PP

Chapter 1 introduction to statistics
Chapter 1 introduction to statisticsChapter 1 introduction to statistics
Chapter 1 introduction to statistics
John Carlo Catacutan

Chap03 numerical descriptive measures
Chap03 numerical descriptive measuresChap03 numerical descriptive measures
Chap03 numerical descriptive measures
Uni Azza Aunillah

Business Statistics Chapter 6
Business Statistics Chapter 6Business Statistics Chapter 6
Business Statistics Chapter 6
Lux PP

Forecasting-Exponential Smoothing
Forecasting-Exponential SmoothingForecasting-Exponential Smoothing
Forecasting-Exponential Smoothing
iceu novida adinata

Introduction to business statistics
Introduction to business statisticsIntroduction to business statistics
Introduction to business statistics
Aakash Kulkarni

Chap02 presenting data in chart & tables
Chap02 presenting data in chart & tablesChap02 presenting data in chart & tables
Chap02 presenting data in chart & tables
Uni Azza Aunillah

Statistics: Chapter One
Statistics: Chapter OneStatistics: Chapter One
Statistics: Chapter One
Saed Jama

Case study on Business Statistics
Case study on Business Statistics Case study on Business Statistics
Case study on Business Statistics
Aditya Purohit

Statistics for management
Statistics for managementStatistics for management
Statistics for management
John Prarthan

Chapter 02
Chapter 02Chapter 02
Chapter 02
bmcfad01


Viewers also liked (20)

Chapter 2
Chapter 2Chapter 2
Chapter 2
Lem Lem

Data collection and presentation
Data collection and presentationData collection and presentation
Data collection and presentation
ferdaus44

Stats chapter 6
Stats chapter 6Stats chapter 6
Stats chapter 6
Richard Ferreria

Stats chapter 5
Stats chapter 5Stats chapter 5
Stats chapter 5
Richard Ferreria

Data Collection Presentation
Data Collection PresentationData Collection Presentation
Data Collection Presentation
Julie Lee

Introduction to statistics
Introduction to statisticsIntroduction to statistics
Introduction to statistics
Andi Koentary

Rm 5 Methods Of Data Collection
Rm   5   Methods Of Data CollectionRm   5   Methods Of Data Collection
Rm 5 Methods Of Data Collection
itsvineeth209

Data vs. information
Data vs. informationData vs. information
Data vs. information
Besar Limani

Chapter 3 Answers
Chapter 3 Answers Chapter 3 Answers
Chapter 3 Answers
cwood

Economic project report
Economic project reportEconomic project report
Economic project report
Gaurav Rastogi GS

Data collection of five star hotel
Data collection of five star hotelData collection of five star hotel
Data collection of five star hotel
Ar. Sahid Akhtar

Introduction to statistics
Introduction to statisticsIntroduction to statistics
Introduction to statistics
madan kumar

Introduction to statistics
Introduction to statisticsIntroduction to statistics
Introduction to statistics
akbhanj

Data collection presentation
Data collection presentationData collection presentation
Data collection presentation
Kanchan Agarwal

Introduction to statistics...ppt rahul
Introduction to statistics...ppt rahulIntroduction to statistics...ppt rahul
Introduction to statistics...ppt rahul
Rahul Dhaker

Statistical ppt
Statistical pptStatistical ppt
Statistical ppt
feminaargonza09

Project on shampoo
Project on shampooProject on shampoo
Project on shampoo
aditya10000

Chapter 3 part1-Design of Experiments
Chapter 3 part1-Design of ExperimentsChapter 3 part1-Design of Experiments
Chapter 3 part1-Design of Experiments
nszakir

Introduction To Statistics
Introduction To StatisticsIntroduction To Statistics
Introduction To Statistics
albertlaporte

Statistics for Class XI (CBSE)
Statistics for Class XI (CBSE)Statistics for Class XI (CBSE)
Statistics for Class XI (CBSE)
mini4deb

Chapter 2
Chapter 2Chapter 2
Chapter 2
Lem Lem

Data collection and presentation
Data collection and presentationData collection and presentation
Data collection and presentation
ferdaus44

Data Collection Presentation
Data Collection PresentationData Collection Presentation
Data Collection Presentation
Julie Lee

Introduction to statistics
Introduction to statisticsIntroduction to statistics
Introduction to statistics
Andi Koentary

Rm 5 Methods Of Data Collection
Rm   5   Methods Of Data CollectionRm   5   Methods Of Data Collection
Rm 5 Methods Of Data Collection
itsvineeth209

Data vs. information
Data vs. informationData vs. information
Data vs. information
Besar Limani

Chapter 3 Answers
Chapter 3 Answers Chapter 3 Answers
Chapter 3 Answers
cwood

Data collection of five star hotel
Data collection of five star hotelData collection of five star hotel
Data collection of five star hotel
Ar. Sahid Akhtar

Introduction to statistics
Introduction to statisticsIntroduction to statistics
Introduction to statistics
madan kumar

Introduction to statistics
Introduction to statisticsIntroduction to statistics
Introduction to statistics
akbhanj

Data collection presentation
Data collection presentationData collection presentation
Data collection presentation
Kanchan Agarwal

Introduction to statistics...ppt rahul
Introduction to statistics...ppt rahulIntroduction to statistics...ppt rahul
Introduction to statistics...ppt rahul
Rahul Dhaker

Project on shampoo
Project on shampooProject on shampoo
Project on shampoo
aditya10000

Chapter 3 part1-Design of Experiments
Chapter 3 part1-Design of ExperimentsChapter 3 part1-Design of Experiments
Chapter 3 part1-Design of Experiments
nszakir

Introduction To Statistics
Introduction To StatisticsIntroduction To Statistics
Introduction To Statistics
albertlaporte

Statistics for Class XI (CBSE)
Statistics for Class XI (CBSE)Statistics for Class XI (CBSE)
Statistics for Class XI (CBSE)
mini4deb

Ad

Similar to Business Statistics Chapter 3 (20)

Mean_Median_Mode.ppthhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh...
Mean_Median_Mode.ppthhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh...Mean_Median_Mode.ppthhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh...
Mean_Median_Mode.ppthhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh...
JuliusRomano3

Measures of central Tendencies Mean_Median_Mode.ppt
Measures of central Tendencies Mean_Median_Mode.pptMeasures of central Tendencies Mean_Median_Mode.ppt
Measures of central Tendencies Mean_Median_Mode.ppt
MathewBuera

Measures of Central Tendency Presentation.ppt
Measures of Central Tendency Presentation.pptMeasures of Central Tendency Presentation.ppt
Measures of Central Tendency Presentation.ppt
anshikagoel52

Measures of central tendency
Measures of central tendencyMeasures of central tendency
Measures of central tendency
Richard Paulino

Measures of central tendency ict integration
Measures of central tendency   ict integrationMeasures of central tendency   ict integration
Measures of central tendency ict integration
Richard Paulino

5.DATA SUMMERISATION.ppt
5.DATA SUMMERISATION.ppt5.DATA SUMMERISATION.ppt
5.DATA SUMMERISATION.ppt
chusematelephone

Krupa rm
Krupa rmKrupa rm
Krupa rm
Krupa Mehta

CABT Math 8 measures of central tendency and dispersion
CABT Math 8   measures of central tendency and dispersionCABT Math 8   measures of central tendency and dispersion
CABT Math 8 measures of central tendency and dispersion
Gilbert Joseph Abueg

Measures of central tendency ict integration
Measures of central tendency   ict integrationMeasures of central tendency   ict integration
Measures of central tendency ict integration
Richard Paulino

Desccriptive statistics
Desccriptive statisticsDesccriptive statistics
Desccriptive statistics
Imtiaz129

Mat 255 chapter 3 notes
Mat 255 chapter 3 notesMat 255 chapter 3 notes
Mat 255 chapter 3 notes
adrushle

Bbs10 ppt ch03
Bbs10 ppt ch03Bbs10 ppt ch03
Bbs10 ppt ch03
Anwar Afridi

Newbold_chap03.ppt
Newbold_chap03.pptNewbold_chap03.ppt
Newbold_chap03.ppt
cfisicaster

Lesson 6 measures of central tendency
Lesson 6 measures of central tendencyLesson 6 measures of central tendency
Lesson 6 measures of central tendency
nurun2010

Statistical ProcessesCan descriptive statistical processes b.docx
Statistical ProcessesCan descriptive statistical processes b.docxStatistical ProcessesCan descriptive statistical processes b.docx
Statistical ProcessesCan descriptive statistical processes b.docx
darwinming1

Lesson03_new
Lesson03_newLesson03_new
Lesson03_new
shengvn

Lesson03_static11
Lesson03_static11Lesson03_static11
Lesson03_static11
thangv

UNIT III -Measures of Central Tendency 2.ppt
UNIT III -Measures of Central Tendency 2.pptUNIT III -Measures of Central Tendency 2.ppt
UNIT III -Measures of Central Tendency 2.ppt
HaiderAli252366

UNIT III -Measures of Central Tendency 2.ppt
UNIT III -Measures of Central Tendency 2.pptUNIT III -Measures of Central Tendency 2.ppt
UNIT III -Measures of Central Tendency 2.ppt
EdwinDagunot4

UNIT III -Measures of Central Tendency 2.ppt
UNIT III -Measures of Central Tendency 2.pptUNIT III -Measures of Central Tendency 2.ppt
UNIT III -Measures of Central Tendency 2.ppt
sanguanryan

Mean_Median_Mode.ppthhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh...
Mean_Median_Mode.ppthhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh...Mean_Median_Mode.ppthhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh...
Mean_Median_Mode.ppthhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh...
JuliusRomano3

Measures of central Tendencies Mean_Median_Mode.ppt
Measures of central Tendencies Mean_Median_Mode.pptMeasures of central Tendencies Mean_Median_Mode.ppt
Measures of central Tendencies Mean_Median_Mode.ppt
MathewBuera

Measures of Central Tendency Presentation.ppt
Measures of Central Tendency Presentation.pptMeasures of Central Tendency Presentation.ppt
Measures of Central Tendency Presentation.ppt
anshikagoel52

Measures of central tendency
Measures of central tendencyMeasures of central tendency
Measures of central tendency
Richard Paulino

Measures of central tendency ict integration
Measures of central tendency   ict integrationMeasures of central tendency   ict integration
Measures of central tendency ict integration
Richard Paulino

CABT Math 8 measures of central tendency and dispersion
CABT Math 8   measures of central tendency and dispersionCABT Math 8   measures of central tendency and dispersion
CABT Math 8 measures of central tendency and dispersion
Gilbert Joseph Abueg

Measures of central tendency ict integration
Measures of central tendency   ict integrationMeasures of central tendency   ict integration
Measures of central tendency ict integration
Richard Paulino

Desccriptive statistics
Desccriptive statisticsDesccriptive statistics
Desccriptive statistics
Imtiaz129

Mat 255 chapter 3 notes
Mat 255 chapter 3 notesMat 255 chapter 3 notes
Mat 255 chapter 3 notes
adrushle

Newbold_chap03.ppt
Newbold_chap03.pptNewbold_chap03.ppt
Newbold_chap03.ppt
cfisicaster

Lesson 6 measures of central tendency
Lesson 6 measures of central tendencyLesson 6 measures of central tendency
Lesson 6 measures of central tendency
nurun2010

Statistical ProcessesCan descriptive statistical processes b.docx
Statistical ProcessesCan descriptive statistical processes b.docxStatistical ProcessesCan descriptive statistical processes b.docx
Statistical ProcessesCan descriptive statistical processes b.docx
darwinming1

Lesson03_new
Lesson03_newLesson03_new
Lesson03_new
shengvn

Lesson03_static11
Lesson03_static11Lesson03_static11
Lesson03_static11
thangv

UNIT III -Measures of Central Tendency 2.ppt
UNIT III -Measures of Central Tendency 2.pptUNIT III -Measures of Central Tendency 2.ppt
UNIT III -Measures of Central Tendency 2.ppt
HaiderAli252366

UNIT III -Measures of Central Tendency 2.ppt
UNIT III -Measures of Central Tendency 2.pptUNIT III -Measures of Central Tendency 2.ppt
UNIT III -Measures of Central Tendency 2.ppt
EdwinDagunot4

UNIT III -Measures of Central Tendency 2.ppt
UNIT III -Measures of Central Tendency 2.pptUNIT III -Measures of Central Tendency 2.ppt
UNIT III -Measures of Central Tendency 2.ppt
sanguanryan

Ad

More from Lux PP (10)

International Business Chapter 16
International Business Chapter 16International Business Chapter 16
International Business Chapter 16
Lux PP

International Business Chapter 13
International Business Chapter 13International Business Chapter 13
International Business Chapter 13
Lux PP

International Business Chapter 12
International Business Chapter 12International Business Chapter 12
International Business Chapter 12
Lux PP

International Business Chapter 11
International Business Chapter 11International Business Chapter 11
International Business Chapter 11
Lux PP

International Business Chapter 10
International Business Chapter 10International Business Chapter 10
International Business Chapter 10
Lux PP

International Business Chapter 9
International Business Chapter 9International Business Chapter 9
International Business Chapter 9
Lux PP

International Business Chapter 08
International Business Chapter 08International Business Chapter 08
International Business Chapter 08
Lux PP

International Business Chapter 07
International Business Chapter 07International Business Chapter 07
International Business Chapter 07
Lux PP

International Business Chapter 06
International Business Chapter 06International Business Chapter 06
International Business Chapter 06
Lux PP

International Business Chapter 11
International Business Chapter 11International Business Chapter 11
International Business Chapter 11
Lux PP

International Business Chapter 16
International Business Chapter 16International Business Chapter 16
International Business Chapter 16
Lux PP

International Business Chapter 13
International Business Chapter 13International Business Chapter 13
International Business Chapter 13
Lux PP

International Business Chapter 12
International Business Chapter 12International Business Chapter 12
International Business Chapter 12
Lux PP

International Business Chapter 11
International Business Chapter 11International Business Chapter 11
International Business Chapter 11
Lux PP

International Business Chapter 10
International Business Chapter 10International Business Chapter 10
International Business Chapter 10
Lux PP

International Business Chapter 9
International Business Chapter 9International Business Chapter 9
International Business Chapter 9
Lux PP

International Business Chapter 08
International Business Chapter 08International Business Chapter 08
International Business Chapter 08
Lux PP

International Business Chapter 07
International Business Chapter 07International Business Chapter 07
International Business Chapter 07
Lux PP

International Business Chapter 06
International Business Chapter 06International Business Chapter 06
International Business Chapter 06
Lux PP

International Business Chapter 11
International Business Chapter 11International Business Chapter 11
International Business Chapter 11
Lux PP


Recently uploaded (20)

Dr Tran Quoc Bao the first Vietnamese CEO featured by The Prestige List - Asi...
Dr Tran Quoc Bao the first Vietnamese CEO featured by The Prestige List - Asi...Dr Tran Quoc Bao the first Vietnamese CEO featured by The Prestige List - Asi...
Dr Tran Quoc Bao the first Vietnamese CEO featured by The Prestige List - Asi...
Ignite Capital

TechnoFacade Innovating Façade Engineering for the Future of Architecture
TechnoFacade Innovating Façade Engineering for the Future of ArchitectureTechnoFacade Innovating Façade Engineering for the Future of Architecture
TechnoFacade Innovating Façade Engineering for the Future of Architecture
krishnakichu7296

A. Stotz All Weather Strategy - Performance review April 2025
A. Stotz All Weather Strategy - Performance review April 2025A. Stotz All Weather Strategy - Performance review April 2025
A. Stotz All Weather Strategy - Performance review April 2025
FINNOMENAMarketing

Brandon Flatley - A Skilled Musician
Brandon Flatley - A Skilled MusicianBrandon Flatley - A Skilled Musician
Brandon Flatley - A Skilled Musician
Brandon Flatley

Reasonable Price To Buy Verified Wise Accounts ( Personal & Business ).pdf
Reasonable Price To Buy Verified Wise Accounts ( Personal & Business ).pdfReasonable Price To Buy Verified Wise Accounts ( Personal & Business ).pdf
Reasonable Price To Buy Verified Wise Accounts ( Personal & Business ).pdf
Topvasmm

The USA’s Most Innovative Startup Company of 2025.pdf
The USA’s Most Innovative Startup Company of 2025.pdfThe USA’s Most Innovative Startup Company of 2025.pdf
The USA’s Most Innovative Startup Company of 2025.pdf
insightssuccess2

72% of Healthcare Organizations Are Expanding Telehealth In 2025—Is Your Bill...
72% of Healthcare Organizations Are Expanding Telehealth In 2025—Is Your Bill...72% of Healthcare Organizations Are Expanding Telehealth In 2025—Is Your Bill...
72% of Healthcare Organizations Are Expanding Telehealth In 2025—Is Your Bill...
alicecarlos1

Paul Turovsky - A Financial Analyst
Paul Turovsky - A Financial AnalystPaul Turovsky - A Financial Analyst
Paul Turovsky - A Financial Analyst
Paul Turovsky

Best Places Buy Verified Cash App Accounts- Reviewed (pdf).pdf
Best Places Buy Verified Cash App Accounts- Reviewed (pdf).pdfBest Places Buy Verified Cash App Accounts- Reviewed (pdf).pdf
Best Places Buy Verified Cash App Accounts- Reviewed (pdf).pdf
Cashapp Profile

HyperVerge's journey from $10M to $30M ARR: Commoditize Your Complements
HyperVerge's journey from $10M to $30M ARR: Commoditize Your ComplementsHyperVerge's journey from $10M to $30M ARR: Commoditize Your Complements
HyperVerge's journey from $10M to $30M ARR: Commoditize Your Complements
xnayankumar

The Fascinating World of Hats: A Brief History of Hats
The Fascinating World of Hats: A Brief History of HatsThe Fascinating World of Hats: A Brief History of Hats
The Fascinating World of Hats: A Brief History of Hats
nimrabilal030

How To Think Like Rick Rubin - Shaan Puri.pdf
How To Think Like Rick Rubin - Shaan Puri.pdfHow To Think Like Rick Rubin - Shaan Puri.pdf
How To Think Like Rick Rubin - Shaan Puri.pdf
Razin Mustafiz

Bloomberg Asia's Power Players in Healthcare - The Visionaries Transforming a...
Bloomberg Asia's Power Players in Healthcare - The Visionaries Transforming a...Bloomberg Asia's Power Players in Healthcare - The Visionaries Transforming a...
Bloomberg Asia's Power Players in Healthcare - The Visionaries Transforming a...
Ignite Capital

How to Transform your Marketing Using AI
How to Transform your Marketing Using AIHow to Transform your Marketing Using AI
How to Transform your Marketing Using AI
Client Marketing Ltd

Mr. Kalifornia Portfolio Group Project Full Sail University
Mr. Kalifornia Portfolio Group Project Full Sail UniversityMr. Kalifornia Portfolio Group Project Full Sail University
Mr. Kalifornia Portfolio Group Project Full Sail University
bmdecker1

Cloud Stream Part II Mobile Hub V2 Cloud Confluency.pdf
Cloud Stream Part II Mobile Hub V2 Cloud Confluency.pdfCloud Stream Part II Mobile Hub V2 Cloud Confluency.pdf
Cloud Stream Part II Mobile Hub V2 Cloud Confluency.pdf
Brij Consulting, LLC

Triwaves India Limited II Bansun Club II Vijay k Sunder
Triwaves India Limited II Bansun Club II Vijay k SunderTriwaves India Limited II Bansun Club II Vijay k Sunder
Triwaves India Limited II Bansun Club II Vijay k Sunder
Uddham Chand

Mastering Fact-Oriented Modeling with Natural Language: The Future of Busines...
Mastering Fact-Oriented Modeling with Natural Language: The Future of Busines...Mastering Fact-Oriented Modeling with Natural Language: The Future of Busines...
Mastering Fact-Oriented Modeling with Natural Language: The Future of Busines...
Marco Wobben

Allan Kinsella: A Life of Accomplishment, Service, Resiliency.
Allan Kinsella: A Life of Accomplishment, Service, Resiliency.Allan Kinsella: A Life of Accomplishment, Service, Resiliency.
Allan Kinsella: A Life of Accomplishment, Service, Resiliency.
Allan Kinsella

Strategic Enterprise Management - Unit I.pptx
Strategic Enterprise Management - Unit I.pptxStrategic Enterprise Management - Unit I.pptx
Strategic Enterprise Management - Unit I.pptx
PrekshyaRana

Dr Tran Quoc Bao the first Vietnamese CEO featured by The Prestige List - Asi...
Dr Tran Quoc Bao the first Vietnamese CEO featured by The Prestige List - Asi...Dr Tran Quoc Bao the first Vietnamese CEO featured by The Prestige List - Asi...
Dr Tran Quoc Bao the first Vietnamese CEO featured by The Prestige List - Asi...
Ignite Capital

TechnoFacade Innovating Façade Engineering for the Future of Architecture
TechnoFacade Innovating Façade Engineering for the Future of ArchitectureTechnoFacade Innovating Façade Engineering for the Future of Architecture
TechnoFacade Innovating Façade Engineering for the Future of Architecture
krishnakichu7296

A. Stotz All Weather Strategy - Performance review April 2025
A. Stotz All Weather Strategy - Performance review April 2025A. Stotz All Weather Strategy - Performance review April 2025
A. Stotz All Weather Strategy - Performance review April 2025
FINNOMENAMarketing

Brandon Flatley - A Skilled Musician
Brandon Flatley - A Skilled MusicianBrandon Flatley - A Skilled Musician
Brandon Flatley - A Skilled Musician
Brandon Flatley

Reasonable Price To Buy Verified Wise Accounts ( Personal & Business ).pdf
Reasonable Price To Buy Verified Wise Accounts ( Personal & Business ).pdfReasonable Price To Buy Verified Wise Accounts ( Personal & Business ).pdf
Reasonable Price To Buy Verified Wise Accounts ( Personal & Business ).pdf
Topvasmm

The USA’s Most Innovative Startup Company of 2025.pdf
The USA’s Most Innovative Startup Company of 2025.pdfThe USA’s Most Innovative Startup Company of 2025.pdf
The USA’s Most Innovative Startup Company of 2025.pdf
insightssuccess2

72% of Healthcare Organizations Are Expanding Telehealth In 2025—Is Your Bill...
72% of Healthcare Organizations Are Expanding Telehealth In 2025—Is Your Bill...72% of Healthcare Organizations Are Expanding Telehealth In 2025—Is Your Bill...
72% of Healthcare Organizations Are Expanding Telehealth In 2025—Is Your Bill...
alicecarlos1

Paul Turovsky - A Financial Analyst
Paul Turovsky - A Financial AnalystPaul Turovsky - A Financial Analyst
Paul Turovsky - A Financial Analyst
Paul Turovsky

Best Places Buy Verified Cash App Accounts- Reviewed (pdf).pdf
Best Places Buy Verified Cash App Accounts- Reviewed (pdf).pdfBest Places Buy Verified Cash App Accounts- Reviewed (pdf).pdf
Best Places Buy Verified Cash App Accounts- Reviewed (pdf).pdf
Cashapp Profile

HyperVerge's journey from $10M to $30M ARR: Commoditize Your Complements
HyperVerge's journey from $10M to $30M ARR: Commoditize Your ComplementsHyperVerge's journey from $10M to $30M ARR: Commoditize Your Complements
HyperVerge's journey from $10M to $30M ARR: Commoditize Your Complements
xnayankumar

The Fascinating World of Hats: A Brief History of Hats
The Fascinating World of Hats: A Brief History of HatsThe Fascinating World of Hats: A Brief History of Hats
The Fascinating World of Hats: A Brief History of Hats
nimrabilal030

How To Think Like Rick Rubin - Shaan Puri.pdf
How To Think Like Rick Rubin - Shaan Puri.pdfHow To Think Like Rick Rubin - Shaan Puri.pdf
How To Think Like Rick Rubin - Shaan Puri.pdf
Razin Mustafiz

Bloomberg Asia's Power Players in Healthcare - The Visionaries Transforming a...
Bloomberg Asia's Power Players in Healthcare - The Visionaries Transforming a...Bloomberg Asia's Power Players in Healthcare - The Visionaries Transforming a...
Bloomberg Asia's Power Players in Healthcare - The Visionaries Transforming a...
Ignite Capital

How to Transform your Marketing Using AI
How to Transform your Marketing Using AIHow to Transform your Marketing Using AI
How to Transform your Marketing Using AI
Client Marketing Ltd

Mr. Kalifornia Portfolio Group Project Full Sail University
Mr. Kalifornia Portfolio Group Project Full Sail UniversityMr. Kalifornia Portfolio Group Project Full Sail University
Mr. Kalifornia Portfolio Group Project Full Sail University
bmdecker1

Cloud Stream Part II Mobile Hub V2 Cloud Confluency.pdf
Cloud Stream Part II Mobile Hub V2 Cloud Confluency.pdfCloud Stream Part II Mobile Hub V2 Cloud Confluency.pdf
Cloud Stream Part II Mobile Hub V2 Cloud Confluency.pdf
Brij Consulting, LLC

Triwaves India Limited II Bansun Club II Vijay k Sunder
Triwaves India Limited II Bansun Club II Vijay k SunderTriwaves India Limited II Bansun Club II Vijay k Sunder
Triwaves India Limited II Bansun Club II Vijay k Sunder
Uddham Chand

Mastering Fact-Oriented Modeling with Natural Language: The Future of Busines...
Mastering Fact-Oriented Modeling with Natural Language: The Future of Busines...Mastering Fact-Oriented Modeling with Natural Language: The Future of Busines...
Mastering Fact-Oriented Modeling with Natural Language: The Future of Busines...
Marco Wobben

Allan Kinsella: A Life of Accomplishment, Service, Resiliency.
Allan Kinsella: A Life of Accomplishment, Service, Resiliency.Allan Kinsella: A Life of Accomplishment, Service, Resiliency.
Allan Kinsella: A Life of Accomplishment, Service, Resiliency.
Allan Kinsella

Strategic Enterprise Management - Unit I.pptx
Strategic Enterprise Management - Unit I.pptxStrategic Enterprise Management - Unit I.pptx
Strategic Enterprise Management - Unit I.pptx
PrekshyaRana


Business Statistics Chapter 3

  • 1. © 2003 Prentice-Hall, Inc. Basic Business Statistics Chapter 3 Numerical Descriptive Measures Chapters Objectives: Learn about Measures of Center. How to calculate mean, median and midrange Learn about Measures of Spread Learn how to calculate Standard Deviation, IQR and Range Learn about 5 number summaries Coefficient of Correlation
  • 2. © 2003 Prentice-Hall, Inc. Chapter Topics  Measures of Central Tendency  Mean, Median, Midrange,  Quartile  Measure of Variation  Range, Interquartile Range, Variance and Standard Deviation, Shape  Symmetric, Skewed, Using Box-and-Whisker Plots
  • 3. © 2003 Prentice-Hall, Inc. Chapter Topics Coefficient of Correlation  Pitfalls in Numerical Descriptive Measures and Ethical Issues (continued)
  • 4. © 2003 Prentice-Hall, Inc. Summary Measures Central Tendency Mean Median Mode Quartile Mid Range Summary Measures Variation Variance Standard Deviation Range Not very good measure
  • 5. © 2003 Prentice-Hall, Inc. The Second Step of Data Analysis  We looked at displaying data using graphs.  But numeric summaries help us to compare variables and to talk about relationships among variables in precise (exact) ways.  After drawing the graph, it is usual to calculate summary values.  This Lesson considers a different numerical summaries.
  • 6. © 2003 Prentice-Hall, Inc. Summaries of Center and Spread Can you think of a way of estimating the  Center of this histogram or  How wide it is (Spread or Variance) Measure of Center Measure of Spread Mean Standard Deviation Media IQR Midrange Range0 5 10 15 20 25 30 30-40 40-50 50-60 60-70 70-80 80-90 90-100 •The shape that appears over the histogram is called the normal distribution shape •This shape is used to estimate the shape of the histogram
  • 7. © 2003 Prentice-Hall, Inc. Finding the Central Value  We summarize the distribution with mean median and midrange  The mean median and midrange have different idea of what is the center, and behaves differently  The Mode is also used however this is not a good measure of the central value
  • 8. © 2003 Prentice-Hall, Inc. Measures of Central Tendency Central Tendency Mean Median Midrange 1 1 n i i N i i X X n X N µ = = = = ∑ ∑
  • 9. © 2003 Prentice-Hall, Inc. Mean (Arithmetic Mean)  Mean (Arithmetic Mean) of Data Values  Sample mean  Population mean 1 1 2 n i i n X X X X X n n = + + + = = ∑ L 1 1 2 N i i N X X X X N N µ = + + + = = ∑ L Sample Size Population Size
  • 10. © 2003 Prentice-Hall, Inc. Mean (Arithmetic Mean)  The Most Common Measure of Central Tendency  Affected by Extreme Values (Outliers) (continued) 0 1 2 3 4 5 6 7 8 9 10 0 1 2 3 4 5 6 7 8 9 10 12 14 Mean = 5 Mean = 6
  • 11. © 2003 Prentice-Hall, Inc.  Approximating the Arithmetic Mean  Used when raw data are not available  Mean (Arithmetic Mean) (continued) 1 sample size number of classes in the frequency distribution midpoint of the th class frequencies of the th class c j j j j j m f X n n c m j f j = = = = = = ∑
  • 12. © 2003 Prentice-Hall, Inc. How to compute the Mean? Step 1: Add all the data points. This is called the SUM or the Total Step 2: Count the number of Data points. This is sometimes called the count Step 3: Divide The Total by the Number of Data points Calculate the mean for the following data points. 5,20,15,3,7 Revision: 5.1 Know how to compute the mean of a collection of data values.
  • 13. © 2003 Prentice-Hall, Inc. Median  Robust Measure of Central Tendency  Not Affected by Extreme Values  In an Ordered Array, the Median is the ‘Middle’ Number  If n or N is odd, the median is the middle number  If n or N is even, the median is the average of the 2 middle numbers 0 1 2 3 4 5 6 7 8 9 10 0 1 2 3 4 5 6 7 8 9 10 12 14 Median = 5 Median = 5
  • 14. © 2003 Prentice-Hall, Inc. Example: Find median of the following numbers 14.1 3.2 25.3 2.8 -17.5 13.9 45.8 Step 1 Order the data 1 2 3 4 5 6 7 -17.5 2.8 3.2 13.9 14.1 25.3 45.8 Step 2 There are 7 values n is odd Step 3 a Median is the middle number Median is 13.9 If we added 35.7 to the above numbers (data set) . What would the median now be? 14.1 3.2 25.3 2.8 -17.5 13.9 45.8 35.7 Step 3 b Median is average of the two middle numbers 5 position 14.1 4 position 13.9 Median = '(13.9+14.1)/2= 14 1 2 3 4 5 6 7 8 -17.5 2.8 3.2 13.9 14.1 25.3 35.7 45.8 Step 1 Order the data n is even Step 2 There are 8 values Calculate the median for the following data points. 5,20,15,3,7 Calculate the median for the following data points. 5,20,15,3,7,10 MEDIAN MEDIAN between 13.9 and 14.1
  • 15. © 2003 Prentice-Hall, Inc. How to compute the Midrange  The range of the data is defined as the difference between the Maximum and Minimum (Range = Max – Min)  What would the Range be in the previous example?  What would the midrange be? (max + min)/2  DISADVANTAGE: - one extreme value can make the midrange very large, so it does not really represent the data.  If you deleted 45.8 and added 1000 to the previous example what would the midrange be? 63.3 14.15 491.25 Calculate the midrange and range for the following data points. 5,20,15,3,7
  • 16. © 2003 Prentice-Hall, Inc. Summary Measures of center  Measures of center are the most commonly used (and misused) summaries of data.  If you understand how they differ and what they really say you can avoid misunderstanding data or being fooled by inappropriate summaries.
  • 17. © 2003 Prentice-Hall, Inc. Mode  A Measure of Central Tendency  Value that Occurs Most Often  Not Affected by Extreme Values  There May Not Be a Mode  There May Be Several Modes  Used for Either Numerical or Categorical Data 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 Mode = 9 0 1 2 3 4 5 6 No Mode
  • 18. © 2003 Prentice-Hall, Inc. Why the mode is not really a measure of center  Often listed among measures of center.  Is it really a central value? 1. The mode of a categorical variable is the category with the highest frequency.  It is not a center in because the categories of a categorical variable have no specific order  we can choose to place the modal category in a bar chart on the right, on the left, or in the middle.. 2. When a continuous distribution is unimodal and symmetric, the single, central mode is often near to other measures of center. 3. Modes of data measured on quantitative variables are rarely useful as measures of center.  It is a coincidence when two quantitative measurements agree exactly,  counting such occurrences tells us little about the variable. As a consequence, statistics packages rarely compute or report modes.
  • 19. © 2003 Prentice-Hall, Inc. Quartiles  Split Ordered Data into 4 Quarters  Position of i-th Quartile  Q1 and Q3 are Measures of Noncentral Location  Q2= Median, a Measure of Central Tendency  The calculation will be covered in the IQR slides. 25% 25% 25% 25% ( )1Q ( )2Q ( )3Q ( ) ( )1 4 i i n Q + = Do not use formula in the Business Statistics BookDo not use formula in the Business Statistics Book
  • 20. © 2003 Prentice-Hall, Inc. Know the differing properties of the mean, median, and midrange  The most common summary value describing a distribution of data values is some measure of a typical or central value.  This can be the mean, median or midrange You have calculate the 3 measures of center (mean, median and midrange) for the following data points. 5,20,15,3,7. 1. Change 15 to 19 and recalculate the mean, median and midrange. Which measures of center have changed? 2. Change 20 to 200 and recalculate the mean, median and midrange. Which measures of center have changed? The median is not effected by outliers like the midrange and Mean The mean is effected by very small changes to data
  • 21. © 2003 Prentice-Hall, Inc. Why Measures Spread?  Spread measures how often something varies.  Imagine you go to a restaurant and received such very good meal, you return for the same meal the next day.  However, this time the food tastes very bad. You never go back. The standard of quality has varied.  The restaurant management needs to be able to control the quality of food.  A key aspect of management is to reduce variability, and provide a consistent quality of service or product  The first step to control variability is to measure it.  Then you can work out what causes the variability  Then work out how to reduce variability.
  • 22. © 2003 Prentice-Hall, Inc. Days of Week The following shows the number of Cakes made by a Bakery in Phnom Penh. It has two bakeries producing identical cakes Day 1 Day 2 Day 3 Day 4 Day 5 Center (Mean) Spread (Std Dev) Bakery A 550 750 800 750 500 670 135 Bakery B 625 670 650 675 630 650 23 Total 1175 1420 1450 1425 1130 The bakery has to produce at least 1200 cakes to meet daily customer demand The bakery has to produce can not produce more than 1400 cakes because customers will not buy them and they will not be eaten 500 550 600 650 700 750 800 Day 1 Day 2 Day 3 Day 4 Day 5 NoCakesbaked Bakery A Bakery B Mean A Mean B Spread A is 135. Variance is very high Spread B is 23 The two bakeries have been baking too many or too few cakes each day. Why?
  • 23. © 2003 Prentice-Hall, Inc. Different Summaries of Spread  Summaries of Spread include  Range  Interquartile Range (IQR) and  Standard Deviation  These summaries highlight different aspects of the distribution and have different values  But they all summarize how the values are spread out.  We have already seen that Range = Max - Min
  • 24. © 2003 Prentice-Hall, Inc. Measures of Variation Variation Variance Standard Deviation Coefficient of Variation Population Variance Sample Variance Population Standard Deviation Sample Standard Deviation Range Interquartile Range
  • 25. © 2003 Prentice-Hall, Inc. Range  Measure of Variation  Difference between the Largest and the Smallest Observations:  Ignores How Data are Distributed Largest SmallestRange X X= − 7 8 9 10 11 12 Range = 12 - 7 = 5 7 8 9 10 11 12 Range = 12 - 7 = 5
  • 26. © 2003 Prentice-Hall, Inc.  Measure of Variation  Also Known as Midspread  Spread in the middle 50%  Difference between the First and Third Quartiles  Not Affected by Extreme Values 3 1Interquartile Range 17.5 12.5 5Q Q= − = − = Interquartile Range Data in Ordered Array: 11 12 13 16 16 17 17 18 21 1317 4
  • 27. © 2003 Prentice-Hall, Inc. 5 Steps to calculate the Interquartile Range (IQR)  Step 1 Put the data in Order  Step 2 Divide the dataset in two. Dataset 1 and Dataset 2.  NOTE: If n is odd the median should be included in both data sets  Step 3 Calculate Q1 (25th Percentile)  If n of Dataset 1 is odd, the Q1 is the middle number of Dataset A  If n of Dataset 1 is even, the median is the average of the 2 middle numbers  Step 4 Calculate Q3 (75th percentile)  As per step 3  Step 5 Find The Interquartile Range (IQR)  IQR= Q3-Q1
  • 28. © 2003 Prentice-Hall, Inc. 5 Steps to Calculate Q1, Q3 and IQR when n is odd In order to calculate IQR we need to to first of all calculate Q1 and Q3. We are going to calculate the Q1, Q3 and IQR for the following dataset: 7,8,25,11,13,5,6 We require to know: Median (Q2 or 50th percentile), Q1 (25th Percentile), Q3 (75th percentile) Step 1 Order Data 1 2 3 4 5 6 7 5 6 7 8 11 13 25
  • 29. © 2003 Prentice-Hall, Inc. Step 2 Divide the dataset in two Divide the above data set into Dataset 1 and Dataset 2. NOTE: If n is odd the median should be included in both data sets Dataset 1 is used to calculate Q1 and Dataset 2 is used to calculate Q3 Dataset 1 For Q1 Data Set 2 For Q3 1 2 3 4 1 2 3 4 5 6 7 8 8 11 13 25 Step 3 Calculate Q1 (25th Percentile) N is even so the Q1 is the average of the 2 middle numbers which is position 2 and 3 Q1 = (6+7)/2 =6.5 (This is the same method used to calculate the median for a even number of data points) 5 Steps Calculate Q1, Q3 and IQR when n is odd (Cont)
  • 30. © 2003 Prentice-Hall, Inc. Step 4 Calculate Q3 (75th percentile) N is even for dataset 2, the median is the average of the 2 middle numbers which is position 2 and 3 Thus, Q3 = (11+13)/2 =12 Step 5 Find The Interquartile Range (IQR) IQR= Q3-Q1 = 12-6.5 =5.5 5 Steps to Calculate Q1, Q3 and IQR when n is odd(Cont) 1 2 3 4 8 11 13 25 Calculate the Q1, Q3 and IQR for the following data points. 5,20,15,3,7,16,4
  • 31. © 2003 Prentice-Hall, Inc. 5 Steps to Calculate Q1, Q3 and IQR when n is EVEN When n is even we we use almost the same process to calculate Q1 Q3 and IQR. In order to calculate IQR we need to to first of all calculate Q1 and Q3. We are going to calculate the Q1, Q3 and IQR for the following dataset: 7,8,25,11,13,5,6 and 30 We require to know: Q1 (25th Percentile), Q3 (75th Step 1 Order Data 1 2 3 4 5 6 7 8 5 6 7 8 11 13 25 30
  • 32. © 2003 Prentice-Hall, Inc. Step 2 Divide the dataset in two Divide the above data set into Dataset 1 and Dataset 2. Dataset 1 is used to calculate Q1 and Dataset 2 is used to calculate Q3 Dataset 1 For Q1 Dataset 2 For Q3 1 2 3 4 1 2 3 4 5 6 7 8 11 13 25 30 Step 3 Calculate Q1 (25th percentile) N is even so the Q1 is the average of the 2 middle numbers which is position 2 and 3 Q1 = (6+7)/2 =6.5 (This is the same method used to calculate the median for a even number of data points) 5 Steps: Calculate Q1, Q3 and IQR when n is even (Cont)
  • 33. © 2003 Prentice-Hall, Inc. Step 4 Calculate Q3 (75th percentile) N is even so the Q1 is the average of the 2 middle numbers which is position 2 and 3 Thus, Q3 = (13+25)/2 =19 Step 5 Find The Interquartile Range (IQR) IQR= Q3-Q1 =19-6.5=12.5 5 Steps to Calculate Q1, Q3 and IQR when n is even (Cont) 1 2 3 4 11 13 25 30 Calculate the Q1, Q3 and IQR for the following data points. 5,20,15,3,7,16,4,30
  • 34. © 2003 Prentice-Hall, Inc. ( ) 2 2 1 N i i X N µ σ = − = ∑  Important Measure of Variation  Shows Variation about the Mean  Sample Variance:  Population Variance: ( ) 2 2 1 1 n i i X X S n = − = − ∑ Variance
  • 35. © 2003 Prentice-Hall, Inc. Standard Deviation  Most Important Measure of Variation  Shows Variation about the Mean  Has the Same Units as the Original Data  Sample Standard Deviation:  Population Standard Deviation: ( ) 2 1 1 n i i X X S n = − = − ∑ ( ) 2 1 N i i X N µ σ = − = ∑
  • 36. © 2003 Prentice-Hall, Inc. How to Calculate the Standard Deviation? Step 1 Step 2 Step 3 Step 4 Count Data (y) Mean (y-Mean) 1 3.4 33.35 -29.95 897 2 20 33.35 -13.35 178 3 63 33.35 29.65 879 4 47 33.35 13.65 186 Total 133.4 2141 Step 5 Mean = SUM/Count =133.4/4=33.35 33.35 Step 6 Total Step 5/( Count -1)=2141/(4-1) = 713.6 Step 7 Square root of 713.6= 26.7 Steps to Calc Standard Deviation 1: Calculate the Mean =Sum/Count Steps to Calc Standard Deviation 1: Calculate the Mean =Sum/Count 2: Enter the mean on each line on the table Steps to Calc Standard Deviation 1: Calculate the Mean =Sum/Count 2: Enter the mean on each line on the table 3: Take the each data point from the mean Steps to Calc Standard Deviation 1: Calculate the Mean =Sum/Count 2: Enter the mean on each line on the table 3: Take the each data point from the mean 4: Square the answer to Step 3 (Multiply each data point by each other) Steps to Calc Standard Deviation 1: Calculate the Mean =Sum/Count 2: Enter the mean on each line on the table 3: Take the each data point from the mean 4: Square the answer to Step 3 (Multiply each data point by each other) 5: Sum the all the data points 6: Divide the total for Step 5 by (Count -1) 7: Calculate the square root of Step 6 Steps to Calc Standard Deviation 1: Calculate the Mean =Sum/Count 2: Enter the mean on each line on the table 3: Take the each data point from the mean 4: Square the answer to Step 3 (Multiply each data point by each other) 5: Sum the all the data points 6: Divide the total for Step 5 by (Count -1) Steps to Calculate Standard Deviation 1: Calculate the Mean =Sum/Count 2: Enter the mean on each line on the table 3: Take the each data point from the mean 4: Square the answer to Step 3 (Multiply each data point by each other) 5: Sum the all the data points Calculate the Standard Deviation for the following data points. 5,20,15,3,7,16,4
  • 37. © 2003 Prentice-Hall, Inc. Histograms to display measures of spread  When the distribution of data is unimodal and symmetric, the middle 38% of the distribution is about one standard deviation wide.  This rule of thumb provides a way to display the standard deviation, but it only applies to unimodal, symmetric distributions.  We can display common measures of spread in a Histogram.
  • 38. © 2003 Prentice-Hall, Inc. Comparing Standard Deviations Mean = 15.5 s = 3.338 11 12 13 14 15 16 17 18 19 20 21 11 12 13 14 15 16 17 18 19 20 21 Data B Data A Mean = 15.5 s = .9258 11 12 13 14 15 16 17 18 19 20 21 Mean = 15.5 s = 4.57 Data C
  • 39. © 2003 Prentice-Hall, Inc. Shape of a Distribution  Describe How Data are Distributed  Measures of Shape  Symmetric or skewed Mean = Median =ModeMean < Median < Mode Mode < Median < Mean Right-SkewedLeft-Skewed Symmetric
  • 40. © 2003 Prentice-Hall, Inc. Describing Distribution: Shape, Center and Spread Start by displaying the distribution of your data. You should describe:  Symmetry vs. skewness * (Look at the tails)  Single vs. multiple modes  Possible outliers separated from the main body of the data. ... But remember that not all distributions have simple shapes. Symmetry Skewness Unimodel Bimodel multimodal Uniform Outliers
  • 41. © 2003 Prentice-Hall, Inc. Identifying Distribution Shape When looking at the distribution of a quantitative variable, consider:  Symmetry,  How many modes it has,  Whether it has any outliers or gaps.
  • 42. © 2003 Prentice-Hall, Inc. Summary: Describing a Distribution  You should always begin analyzing data by graphing the distributions of the variables.  We describe the shape of the distribution of a quantitative variable by noting whether it is symmetric or skewed, unimodal, bimodal, or multimodal.  Following the general rule that we first describe a pattern and then look for deviations from that pattern, we look at distributions to see if there are straggling outliers or gaps in the distribution shape.  Each of these descriptions is quite general and vague, so people may disagree on the "close calls." Nevertheless, we usually begin describing data by summarizing the distribution shapes.
  • 43. © 2003 Prentice-Hall, Inc. Exploratory Data Analysis  Box-and-Whisker  NOTE: Different from Basic Business Statistics Book!  Graphical display of data using 5-number summary Median( ) 4 6 8 10 12 Top of Whiskers Bottom of Whiskers 1Q 3Q 2Q
  • 44. © 2003 Prentice-Hall, Inc. Distribution Shape & Box-and-Whisker Right-SkewedLeft-Skewed Symmetric 1Q 1Q 1Q2Q 2Q 2Q3Q 3Q3Q
  • 45. © 2003 Prentice-Hall, Inc. The Empirical Rule  For Most Data Sets, Roughly 68% of the Observations Fall Within 1 Standard Deviation Around the Mean  Roughly 95% of the Observations Fall Within 2 Standard Deviations Around the Mean  Roughly 99.7% of the Observations Fall Within 3 Standard Deviations Around the Mean
  • 46. © 2003 Prentice-Hall, Inc. Coefficient of Correlation  Measures the Strength of the Linear Relationship between 2 Quantitative Variables  ( )( ) ( ) ( ) 1 2 2 1 1 n i i i n n i i i i X X Y Y r X X Y Y = = = − − = − − ∑ ∑ ∑
  • 47. © 2003 Prentice-Hall, Inc. Features of Correlation Coefficient  Unit Free  Ranges between –1 and 1  The Closer to –1, the Stronger the Negative Linear Relationship  The Closer to 1, the Stronger the Positive Linear Relationship  The Closer to 0, the Weaker Any Linear Relationship
  • 48. © 2003 Prentice-Hall, Inc. Scatter Plots of Data with Various Correlation Coefficients Y X Y X Y X Y X Y X r = -1 r = -.6 r = 0 r = .6 r = 1
  • 49. © 2003 Prentice-Hall, Inc. Scatter Plots  Best way to see relationships between two Quantitative Variables  If there is a relationship it is called an association. Scatter plots are the best way to look for associations Relationship of Class Attended and Statitstics Score 20 25 30 35 40 45 50 55 60 65 70 4 6 8 10 12 14 Number Classes Attended Score
  • 50. © 2003 Prentice-Hall, Inc. Scatter Plots  Only Quantitative Variables can be used  The following is the relationship between the Mango Taste Score and the Number of Weeks it grown for Weeks Grown on Tree Time taken to grow the best Mango 0 20 40 60 80 100 6 8 10 12 14 16 18 TasteScore
  • 51. © 2003 Prentice-Hall, Inc. Direction: Positive 0 10 20 30 40 50 60 70 80 90 100 0 1 2 3 4 5 6 Scatter Plots : DIRECTION and FORM Negtive Direction 0 10 20 30 40 50 60 70 80 90 0 1 2 3 4 5 6 •Direction: +Ve •Form: Linear (Straight Line) •Direction: +Ve •Form: Linear (Straight Line)
  • 52. © 2003 Prentice-Hall, Inc. Form describes the shape  Describe the Form if there is one. EG Straight, or arched or curved A Curve 0 2 4 6 8 10 12 14 16 18 20 0 1 2 3 4 5 6 An Arch 0 20 40 60 80 100 6 8 10 12 14 16 18 TasteScore
  • 53. © 2003 Prentice-Hall, Inc. Scatter: The following Scatter Plots have no scatter 0 50 100 150 200 250 0 5 10 15 20 0 5 10 15 20 25 30 0 2 4 6 8 10 12 •The third thing to look for is scatter. •These graphs have no Scatter because the dots follow each other in a line.
  • 54. © 2003 Prentice-Hall, Inc. Scatter: The following Scatter Plots have scatter •These graphs have Scatter because the dots are like a cloud. •Always look for something you do not expect to find •One Graph has an outlier which are very important unexpected points that may occur 0 2 4 6 8 10 12 0 10 20 30 40 50 0 10 20 30 40 50 60 70 80 90 0 10 20 30 40 50 60
  • 55. © 2003 Prentice-Hall, Inc. How to Measure Scatter: Correlation Coefficient, r I X Y 1 2 5 -4 -10 40 2 4 10 -2 -5 10 3 6 15 0 0 0 4 8 20 2 5 10 5 10 25 4 10 40 Total 30 75 100 Mean 6 15 Standard Deviation 3.162278 7.905694 Sx = 3.162278 Sy = 7.905694 1 905694.7*162278.3*)15( 100 )1( )(*)( = − = − −− = ∑ SxSyn yyxx CorrCoef xx − xx − yy − )(*)( yyxx −−
  • 56. © 2003 Prentice-Hall, Inc. Plot Chart and describe scatter plot. Calculate Correlation Coefficient 0 10 20 30 0 5 10 15 X Y These data points go in straight line with no scatter in a positive direction (positively correlated) 1 905694.7*162278.3*)15( 100 )1( )(*)( = − = − −− = ∑ SxSyn yyxx CorrCoef Step 1: Draw Scatter Plot Step 2: Write Description Step 3: If there is a linear (Straight line) relationship calculate
  • 57. © 2003 Prentice-Hall, Inc. Example 2  For the following data, plot a scatter plot and describe it. Calculate Correlation Coefficient n X Y X-Mean X Y-Mean X Product 1 4 22 -2 7.6 -15.2 2 5 23 -1 8.6 -8.6 3 6 12 0 -2.4 0 4 7 13 1 -1.4 -1.4 5 8 2 2 -12.4 -24.8 Total 30 72 -50 Mean 6 14.4 Standard Deviation 1.581139 8.561542
  • 58. © 2003 Prentice-Hall, Inc. Answer: Example 2 n X Y 1 4 22 -2 7.6 -15.2 2 5 23 -1 8.6 -8.6 3 6 12 0 -2.4 0 4 7 13 1 -1.4 -1.4 5 8 2 2 -12.4 -24.8 Total 30 72 -50 Mean 6 14.4 Standard Deviation 1.581139 8.561542 These data points go in straight line with some scatter in a negative direction (negatively correlated) 0 5 10 15 20 25 3 4 5 6 7 8 9 x y 92.0 1214.9*5811.1*)15( 50 )1( )(*)( −= − − = − −− = ∑ SxSyn yyxx CorrCoef xx − yy − )(*)( yyxx −−
  • 59. © 2003 Prentice-Hall, Inc. Example 3  For the following data, plot a scatter plot and describe it. Calculate Correlation Coefficient n X Y X-Mean X Y-Mean X Product 1 1 5 -2 -10.2 20.4 2 2 21 -1 5.8 -5.8 3 3 25 0 9.8 0 4 4 19 1 3.8 3.8 5 5 6 2 -9.2 -18.4 Total 15 76 0 Mean 3 15.2 Standard Deviation 1.581139 9.121403
  • 60. © 2003 Prentice-Hall, Inc. Answer: Example 3 n X Y 1 1 5 -2 -10.2 20.4 2 2 21 -1 5.8 -5.8 3 3 25 0 9.8 0 4 4 19 1 3.8 3.8 5 5 6 2 -9.2 -18.4 Total 15 76 0 Mean 3 15.2 Standard Deviation 1.581139 9.121403 0 10 20 30 0 2 4 6 X Y These data points are in an arched shape with a little scatter. 0 1214.9*5811.1*)15( 0 )1( )(*)( = − = − −− = ∑ SxSyn yyxx CorrCoef xx − yy − )(*)( yyxx −−
  • 61. © 2003 Prentice-Hall, Inc. Example 4  For the following data, plot a scatter plot and describe it. Calculate Correlation Coefficient n X Y X-Mean X Y-Mean X Product 1 1 17 -4.4 5.8 -25.52 2 3 1 -2.4 -10.2 24.48 3 6 22 0.6 10.8 6.48 4 7 3 1.6 -8.2 -13.12 5 10 13 4.6 1.8 8.28 Total 27 56 0.6 Mean 5.4 11.2 Standard Deviation 3.507136 9.011104
  • 62. © 2003 Prentice-Hall, Inc. Answer: Example 4 n X Y X-Mean X Y-Mean X Product 1 1 17 -4.4 5.8 -25.52 2 3 1 -2.4 -10.2 24.48 3 6 22 0.6 10.8 6.48 4 7 3 1.6 -8.2 -13.12 5 10 13 4.6 1.8 8.28 Total 27 56 0.6 Mean 5.4 11.2 Standard Deviation 3.507136 9.011104 0 10 20 30 0 5 10 15 X Y 0.005 9.011*3.5071*1)(5 6.0 1)SxSy(n )y(y*)x(x CorrCoef = − = − −− = ∑ These data points have a lot of scatter and they are not correlated
  • 63. © 2003 Prentice-Hall, Inc. Pitfalls in Numerical Descriptive Measures and Ethical Issues  Data Analysis is Objective  Should report the summary measures that best meet the assumptions about the data set  Data Interpretation is Subjective  Should be done in a fair, neutral and clear manner  Ethical Issues  Should document both good and bad results  Presentation should be fair, objective and neutral  Should not use inappropriate summary measures to distort the facts
  • 64. © 2003 Prentice-Hall, Inc. Chapter Summary  Described Measures of Central Tendency  Mean, Median, Midrange  Discussed Quartiles  Described Measures of Variation  Range, Interquartile Range, Variance and Standard Deviation  Illustrated Shape of Distribution  Symmetric, Skewed, Using Box-and-Whisker Plots
  • 65. © 2003 Prentice-Hall, Inc. Chapter Summary  Described the Empirical  Discussed Correlation Coefficient  Addressed Pitfalls in Numerical Descriptive Measures and Ethical Issues (continued)
